The ultimate compact 3-way studio speakers... the KS Digital C55 Active Studio Nearfield Monitor
The KS Digital C55 is a self-powered, tri-amplified, full-bandwidth 3-way speaker
 |
 |
 |
|
The C55 builds on the compact design of the C5 by doubling the cabinet and adding an additional woofer. It is the finest example of precision German engineering in sound; featuring a 180W bass amplifier, 180W midrange amp, 80W high frequency amp, 42 Hz to 28 kHz frequency response, and full dynamic range. Put them up against competitors twice their size, and you'll hear the difference that no phase distortion, super-accurate spatial imaging, and absolute transparency give you... the sonic truth.
|
Contained inside is a handmade LF 6.5" carbon fiber woofer and 6.5" midrange carbon fiber waveguide cone, with a separately-mounted center HF driver. For precise coaxial performance, these time-aligned drivers mean there are no dispersion anomalies vertically or horizontally, and the C55's optimal impulse response means excellent frequency response and phase coherency. The resulting sound output is precise and sonically neutral, giving you the most accurate 3-way nearfield experience you've ever heard. It includes magnetic shielding, so it's safe to use next to your computer monitor.
|
The fast-acting MOSFET power amps are mounted on the back of the speaker, as well as an XLR input, volume control, bass level control, high frequency level control, low frequency bass port, IEC power, and on/off switch. For those engineers who need to hear bass frequencies extended as low as possible, add the B2 or B3 subwoofer... although the C55's perform admirably even without. Step up to a new era of compact 3-way nearfield studio monitoring... the C55 sets a new standard for precision audio. Like all our nearfield studio speakers, the KS Digital C55 is hand-built in Germany for you and comes with a signed Certificate of Authenticity, as well as a full 2-year warranty.
|
C55 Technical Specification
Reviews:
… Designed as a full-range studio monitor, this coax with an additional subwoofer delivers a powerful sound at any volume, with no smearing or coloration to the mix.
… It’s an almost ideal point source, which at the listening position reproduces a clean sound with no phase distortion.
… In home and project studios with more unmusical mixing environments, the C55 shows it true strength by supplying a reliable, honest sound image and great depth.
… The 3-way monitors (C55, C88) can absolutely be put in a mid-distance listening field due to their powerful sub driver and amplifier headroom. The sound is impressive, regardless of the volume level.
… The C55 is well balanced and neutral, with high separation of individual sound sources, fantastic spatial presentation, and excellent frequency and dynamic response…
… The tonality is balanced and features an absolutely precise point source, which results in great pleasure when listening.
… With the Coax monitors C55 and C88, KS Digital has released two studio monitors, which are both highly interesting and professional. Top-notch components, plenty of amplifier headroom, and a great design concept for both models results in excellent measurements at any volume level. Sound-wise, the speakers are neutral and reproduce a wide frequency range. Also impressive is the spatial imaging precision.
- Frequency response: 42 - 28,000 Hz ( +/-3dB)
- Sound Pressure Level peak: 109 dB
- Drivers: 6.5" carbon fiber woofer, 6.5" carbon fiber cone as waveguide for 1.45" cloth dome, neodynium magnet
- Weight: 12.5 kg, 27.5 lbs
- Dimensions H 44 x W 22 x D 22 cm, 17 1/3" x 9" x 9"
- Mosfet Bass amplifier output power: 180 W
- Mosfet Treble amplifier output power: 180 W + 80 W
- Mains voltage: 100, 120, 220 or 230 V according to region
- Voltage operating range: +/- 10%
- Input connector XLR female analog, balanced: Pin 1 gnd, pin 2+, pin 3-
- Input impedance: 10 kOhm balanced
- Input Level Control: Variable from -10dB to +6dB
- Crossover frequency, Bass/Treble: 2.5 kHz with Bessel 18dB per octave
- Adjustment in signal processing: Stepless adjustment -6dB to +6dB in bass/treble
- Controls: gain, bass, high
